American National Standards Institute（ANSI transformer standards）

Writer： Hengfeng you electric Time：2023-05-09 views：times

ANSI: American National Standards Institute, founded in 1918, is organized by American Society for testing and materials (ASTM), American Society of Mechanical Engineers (ASME), American Society of mining and Metallurgical Engineers (asmme), American Society of Civil Engineers (ASCE), American Institute of Electrical Engineers (AIEE), etc, The American Engineering Standards Committee (AESC) was jointly established, and three departments of the U.S. government (Commerce Department, Army Department and Navy Department) also participated in the preparation of the Committee.

In 1928, the American Engineering Standards Committee was reorganized into the American Standards Association (ASA), which is committed to the cause of international standardization and the standardization of consumer goods.

In August 1966, it was reorganized as the Standards Institute of the United States of America (USASI).

On October 6, 1969, it was changed to its current name: American National Standards Institute (ANSI), which continues to this day.

The U.S. medium voltage grid voltage is:

12470Y/7200

13200Y/7620

24940Y/14400

34500Y/19920

The low voltage is:

Voltage: 120 / 240V (single phase), 208 / 240V (three phases); Frequency: 60Hz

编号	中文名称	英文名称
ANSI C12.9-2005	变压器额定仪表用测试开关	Test Switches for Transformer-Rated Meters
ANSI C57.12.10-1998	电压不大于230千伏且容量为833/958至8333/10417千伏安单相及750/862至60000/80000/100000千伏安三相的变压	Transformers 230 kV and Below, 833/958 through 8333/10 417 kVA Single Phase, and 750/862 through 60 000/80 000/100 000 kVA Three Phase, Requirements for
ANSI C57.12.20-1997	变压器.不大于500kVA的架空配电变压器:高压不大于34500伏、低压不大于 7970/13800Y伏	Transformers - Overhead-Type Distribution Transformers, 500 kVA and Smaller: High Voltage, 34 500 Volts and Below; Low Voltage, 7970/13 800Y Volts and Below
ANSI C57.12.24-2000	变压器.不大于2500kVA的地下型三相配电变压器:高压不大于34500Y接地/19920伏、低压不大于480伏.要求	Transformers - Underground-Type Three-Phase Distribution Transformers, 2500 kVA and Smaller: High Voltage 34 500 Grd Y/19 920 Volts and Below; Low Voltage, 480 Volts and Below - Requirements
ANSI C57.12.50-1981	高压601至34500伏,低压120至600伏,容量单相1至500千伏安和三相15至500千伏安,通风干式配电变压器的要求	Ventilated Dry-Type Distribution Transformers, 1 to 500 kVA, Single-Phase and 15 to 500 kVA, Three-Phase, with High-Voltage 601 to 34 500 Volts, Low-Voltage 120 to 600 Volts, Requirements for; Correction June 1982
ANSI C57.12.51-1981	三相，高压601至34500伏,低压208Y/120至4160伏容量不小于501千伏安,通风干式电力变压器的要求	Requirements for Ventilated Dry-Type Power Transformers, 501 kVA and Larger, Three-Phase, with High-Voltage 601 to 34 500 Volts, Low-Voltage 208Y/120 to 4160 Volts
ANSI C57.12.52-1981	三相，高压:601至34500伏，低压:208Y/120至4160伏,容量不小于501千伏安,密封干式电力变压器的要求	Requirements for Sealed Dry-Type Power Transformers, 501 kVA and Larger, Three-Phase, with High-Voltage 601 to 34 500 Volts, Low-Voltage 208Y/120 to 4160 Volts
ANSI C57.12.55-1987	变压器.包括成套变电所在内的成套设备用干式变压器.一致性标准	Transformers - Dry-Type Transformers Used in Unit Installations, Including Unit Substations - Conformance Standard
ANSI C82.7-1983	水银灯变压器.恒定电流(系列)供电型	Mercury Lamp Transformers - Constant-Current (Series) Supply Type
ANSI C82.8-1988	灯变压器.白炽灯变压器.恒定电流(系列)供电型	Lamp Transformers - Incandescent Filament Lamp Transformers - Constant-Current (Series) Supply Type
ANSI C82.9-1996	高亮度放电和低压钠灯、镇流器和变压器.定义	High-Intensity-Discharge and Low-Pressure Sodium Lamps, Ballasts and Transformers - Definitions
ANSI C82.9b-1998	电灯镇流器.高强度放电和低压钠灯镇流器和变压器的定义	Electric Lamp Ballasts - High-Intensity-Discharge and Low-Pressure Sodium Lamps, Ballasts and Transformers - Definitions
ANSI/ASTM A1009-2000	高频(10KHz-1MHz)电源变压器和过滤电感器软磁化锰锌铁芯材料规范	Specification for Soft Magnetic MnZn Ferrite Core Materials for High Frequency (10KHz to 1MHz) Power Transformer and Filter Inductor Applications
ANSI/IEEE 111-2000	宽带（大于10倍频程）变压器标准	Standard for Wide Band (Greater than 1 Decade) Transformers
ANSI/IEEE 1538-2000	充液变压器的最大绕组温升的测定指南	Guide for Determination of Maximum Winding Temperature Rise in Liquid Filled Transformers
ANSI/IEEE 295-1969	电子设备电力变压器	Electronics Power Transformers
ANSI/IEEE 388-1992	电子功率变换设备中的变压器和感应线圈	Transformers and Inductors in Electronic Power Conversion Equipment
ANSI/IEEE 389-1996	测试电子电路变压器和感应器的推荐实施规程	Recommended Practice for Testing Electronic Transformers and Inductors
ANSI/IEEE 436-1991	电子电路变压器产生电晕(局部放电)的测量指南	Guide for Making Corona (Partial Discharge) Measurements on Electronics Transformers
ANSI/IEEE 62-1995	电力设备的诊断现场试验指南.第1部分:充油电力变压器、调节器和电抗器	Guide for Diagnostic Field Testing of Electric Power Apparatus - Part 1: Oil Filled Power Transformers, Regulators, and Reactors
ANSI/IEEE 638-1992	核电站用IE级变压器的合格鉴定	Standard for Qualification of Class 1E Transformers for Nuclear Power Generating Stations
ANSI/IEEE C37.108-2002	保护网络变压器指南	Guide for the Protection of Network Transformers
ANSI/IEEE C37.91-2000	电力变压器的保护继电器应用指南	Protective Relay Applications to Power Transformers, Guide for
ANSI/IEEE C57.100-1999	油浸式配电变压器热评定试验规程	Distribution Transformers, Test Procedure for Thermal Evaluation of Oil-Immersed
ANSI/IEEE C57.105-1992	三相配电系统变压器连接申请	Application of Transformer Connections in Three-Phase Distribution Systems
ANSI/IEEE C57.109-1993	液浸式变压器穿越故障电流持续时间的指南	Guide for Liquid-Immersed Transformer Through-Fault Current Duration
ANSI/IEEE C57.110-2004	施加非正弦负载电流时变压器性能确定的推荐实施规程	Recommended Practice for Establishing Transformer Capability When Supplying Nonsinusoidal Load Currents
ANSI/IEEE C57.111-1995	硅绝缘液体验收指南和在变压器中的维护	Guide for Acceptance of Silicone Insulating Fluid and Its Maintenance in Transformers
ANSI/IEEE C57.113-2002	充液电力变压器和并联电抗器的局部放电测量指南	Guide for Partial Discharge Measurement in Liquid-Filled Power Transformers and Shunt Reactors
ANSI/IEEE C57.116-1990	直接连于发电机的变压器指南	Guide for Transformers Directly Connected to Generators
ANSI/IEEE C57.117-1986	公用电力系统的电力变压器和并联电抗器失效数据报告指南	Reporting Failure Data for Power Transformers and Shunt Reactors on Electric Utility Power Systems, Guide for
ANSI/IEEE C57.119-2002	超出铭牌额定值的负荷下进行油浸电力变压器升温试验的推荐惯例	Recommended Practice for Performing Temperature Rise Tests on Oil Immersed Power Transformers at Loads Beyond Nameplate Ratings
ANSI/IEEE C57.12.01-2005	包括固体浇铸和/或树脂密封绕组的干式配电和电力变压器的标准.一般要求	Standard General Requirements for Dry-Type Distribution and Power Transformers Including Those with Solid-Cast and/or Resin Encapsulated Windings
ANSI/IEEE C57.12.20-2005	500 kVA及更小的顶置式配电变压器的标准:高压34500V及以下、低压7970/13800Y伏特及以下	Standard for Overhead Type Distribution Transformers, 500 kVA and Smaller: High Voltage, 34 500 Volts and Below; Low Voltage, 7970/13 800Y Volts and Below
ANSI/IEEE C57.12.23-2002	变压器.带可分离绝缘高压连接器的地下型、自冷式单相配电变压器.高压(24940GrdV/14400V及以下)和低压(240/1	Transformers - Underground-Type, Self-Cooled, Single-Phase Distribution Transformers with Separable, Insulated, High-Voltage Connectors; High Voltage (24 940 GrdY/14 400 V and Below) and Low Voltage (240/120 V, 167 kVA and Smaller)
ANSI/IEEE C57.12.34-2004	底座安装的隔室型自冷式三相配电变压器2500 kVA及更小:高压34500 GrdY/19920伏及以下、低压480伏及以下的要	Standard Requirements for Pad-Mounted, Compartmental-Type, Self-Cooled, Three-Phase Distribution Transformers, 2500 kVA and Smaller: High-Voltage, 34 500 GrdY/19 920 Volts and Below; Low Voltage, 480 Volts and Below
ANSI/IEEE C57.12.35-1996	配电变压器的标准条形编码	Standard Bar Coding for Distribution Transformers
ANSI/IEEE C57.12.56-1994	通风干燥型电力和配电变压器绝缘系统热评价的试验程序	Test Procedure for Thermal Evaluation of Insulation Systems for Ventilated Dry-Type Power and Distribution Transformers (reinstatement of administratively withdrawn standard)
ANSI/IEEE C57.12.58-1991	干式变压器线圈瞬态电压分析指南	Guide for Conducting a Transient Voltage Analysis of a Dry Type Transformer Coil
ANSI/IEEE C57.12.59-2002	干式变压器全故障电流持续时间指南	Guide for Dry-Type Transformer Through-Fault Current Duration
ANSI/IEEE C57.12.60-1998	固体浇铸和树脂密封的电力和配电变压器绝缘系统热评定试验程序指南	Guide for Test Procedures for Thermal Evaluation of Insulation Systems for Solid Cast and Resin-Encapsulated Power and Distribution Transformers
ANSI/IEEE C57.12.70-2000	输电及电力变压器用终端标志和连接标准	Standard Terminal Markings and Connections for Distribution and Power Transformers
ANSI/IEEE C57.12.80-2002	电力分配变压器术语	Terminology for Power and Distribution Transformers
ANSI/IEEE C57.12.90-1999	油浸式配电、电力和调压变压器的试验规程及电力和配电变压器短路试验指南	Test Code for Liquid-Immersed Distribution, Power and Regulating Transformers and Guide for Short-Circuit Testing of Distribution and Power Transformers
ANSI/IEEE C57.120-1992	电力变压器和电抗器的损耗评价指南	Loss Evaluation Guide for Power Transformers and Reactors
ANSI/IEEE C57.123-2002	变压器损失测量指南	Guide for Transformer Loss Measurement
ANSI/IEEE C57.124-1991	干式变压器表观电荷部分放电和测量的检测	Detection of Partial Discharges and the Measurement of Apparent Charge in Dry Type Transformers
ANSI/IEEE C57.125-2005	电力变压器和分流扼流器故障研究、记录和分析指南	Guide for Failure Investigation, Documentation, and Analysis for Power Transformers and Shunt Reactors
ANSI/IEEE C57.13-2003	仪表用变压器标准要求	Standard Requirements for Instrument Transformers
ANSI/IEEE C57.13.1-1981	继电器用的电流变压器现场测试指南	Field Testing of Relaying Current Transformers
ANSI/IEEE C57.13.2-2005	仪表用变压器标准合格测试程序	Standard Conformance Test Procedure for Instrument Transformers
ANSI/IEEE C57.13.3-2005	仪表用变压器次级线圈电路和外壳接地指南	Guide for Grounding of Instrument Transformer Secondary Circuits and Cases
ANSI/IEEE C57.13.6-2005	高精度仪表变压器标准	Standard for High Accuracy Instrument Transformers
ANSI/IEEE C57.134-2000	干式变压器热斑温度测定指南	Guide for Determination of Hottest Spot Temperature in Dry Type Transformers
ANSI/IEEE C57.135-2001	移相变压器的应用、规范和测试指南	Guide for the Application, Specification and Testing of Phase-Shifting Transformers
ANSI/IEEE C57.136-2000	额定功率大于500kVA的油浸式电力变压器和并联电抗器的声级抑制和测定指南	Guide for Sound Level Abatement & Determination for Liquid-Immersed Power Transformers & Shunt Reactors Rated Over 500 kVA
ANSI/IEEE C57.138 (R200x)-1998	配电变压器常规脉冲试验的推荐实施规程	Recommended Practice for Routine Impulse Test for Distribution Transformers
ANSI/IEEE C57.138-1998	配电变压器常规脉冲试验推荐惯例	Recommended Practice for Routine Impulse Test for Distribution Transformers
ANSI/IEEE C57.144-2004	变压器标准的米制转换指南	Guide for Metric Conversion of Transformer Standards
ANSI/IEEE C57.146-2005	硅树脂浸变压器产生气体的说明指南	Guide for the Interpretation of Gases Generated in Silicone-Immersed Transformers
ANSI/IEEE C57.18.10-1998	半导体电力整流变压器要求和标准实施规程	Standard Practices and Requirements for Semiconductor Power Rectifier Transformers
ANSI/IEEE C57.91-2004	矿物油浸式变压器的加载指南	Guide for Loading Mineral-Oil-Immersed Transformers
ANSI/IEEE C57.93-1995	液浸式电力变压器的安装指南	Guide for Installation of Liquid Immersed Power Transformers
ANSI/IEEE C57.94-2000	干式通用配电及电力变压器的安装、应用、操作和维护的推荐规程	Recommended Practice for Installation, Application, Operation, and Maintenance of Dry-Type General-Purpose Distribution and Power Transformers
ANSI/IEEE C57.96-1999	负载干式配电和电源变压器指南	Distribution and Power Transformers, Guide for Loading Dry-Type (appendix to ANSI C57.12 standards)
ANSI/IEEE C57.98-1993	变压器脉冲试验指南	Impulse Tests, Guide for Transformer (appendix to ANSI/IEEE C57.12.90)
ANSI/NECA 409-2002	干式变压器的安装和维护的推荐规程	Recommended Practice for Installing and Maintaining Dry-Type Transformers
ANSI/NECA 410-2005	充液变压器安装和维修标准	Standard for Installing and Maintaining Liquid-Filled Transformers
ANSI/NETA MTS7.2.1-2001	干式变压器NETA维护测试规范:气冷600V及以下.小型(167kV单相,500kVA三相及更小)和气冷600V及以下.大型(大于	NETA Maintenance Testing Specifications for Dry-Type Transformers: Air-Cooled, 600 Volts and Below - Small (167 kV Single-Phase, 500 kVA Three-Phase, and Smaller) and Air-Cooled, All Above 600 Volts and 600 Volts and Below - Large (Greater than 167 kV Single-Phase and 500 kVA Three-Phase)
ANSI/NETA MTS7.2.2-2001	充液变压器维护测试规范	Maintenance Testing Specifications for Liquid-Filled Transformers
ANSI/SCTE 68-2003	无源电压降:匹配变压器75ohm到300ohm	Drop Passives: Matching Transformers 75 ohm to 300 ohm
ANSI/UL 1310-2005	直接插入式变压器设备	Direct Plug-in Transformer Units
ANSI/UL 1561-2005	干式通用和电力变压器	Dry-Type General Purpose and Power Transformers
ANSI/UL 506-2005	专用变压器	Specialty Transformers
ANSI/UL 551-1993	变压器型弧焊机	Transformer-Type Arc-Welding Machines
ANSI/UL 697-2004	玩具变压器	Toy Transformers
ASTM A 1009-2005	高频(10kHz-1MHz)电力变压器和滤波感应器用软磁性MnZn铁芯材料标准规范	Standard Specification for Soft Magnetic MnZn Ferrite Core Materials for High Frequency (10 kHz-1 MHz) Power Transformer and Filter Inductor Applications
ASTM D 2759-2000	在正压力下从变压器中抽取气体样品的标准实施规程	Standard Practice for Sampling Gas from a Transformer Under Positive Pressure
ASTM D 3305-1994	从变压器中抽取小体积气体样品的标准实施规程	Standard Practice for Sampling Small Gas Volume in a Transformer
UL 1411-1998	音频、无线电和电视类装置用变压器与电机变压器	(Transformers and motor transformers for use in audio-, radio-, and television-type appliances )
UL 1561-1999	干式通用电力变压器	(Dry-type general purpose power transformers )
UL 1562-1999	干式600V以上变压器、配电系统	(Transformers, distribution, dry-type over 600 volts )
UL 1585-1998	2类和3类变压器	(Class 2 and class 3 transformers )
UL 1876-2001	电子设备中隔离和反馈信号用变压器	(Isolating signal and feedback transformers for use in electronic equipment )
UL 2161-1996	氖变压器和电力电源	(Neon transformers and power supplies )
UL 551-1994	变压器型弧焊机	(Transformer-type arc-welding machines )
UL 697-1998	玩具用变压器	(Toy transformers )
