Manufacturer
HENGFENGYOU ELECTRIC
Standard on which performance data is based
IEC 60076,GB 1094-1996,GB/ T6451-2008,GB/T 7597-2007
Type
OIL IMMERSED
Method of Cooling
ONAN
Rated Power
150000 KVA
Voltage Ratio
132kv/6.3kv 132kv/6.6 kv 132kv/10.5kv 132kv/11kv
Frequency
50/60HZ
Tap Changer
5
HV·Tapping
±2×2.5%;±8×1.25%
Vector Group
YNd11
Core Material
CRGO Steel
Winding Material
Alumnium or Copper
No Load Losses (GB/T S13 series)
101kw
Load Losses (GB/T S13 series)
385kw
Dimensions of Transformer
a-Approximate overall length (A)
b-Approximate overall width (B)
c-Approximate overall height(C)
